MD1284

GET A QUOTE
ENGLISH
1
1

MD1284

Part IconRear Brake
SPECIFICATION ICON SPECIFICATION

    • Location

      Rear Brake

    • Width

      116.8 mm

    • Height

      48.4 mm

    • Thickness

      15 mm

CROSS REFERENCE ICON CROSS REFERENCE

    • FMSI

      D1284-8524

    • HI-Q

      SP4231

    • HYUNDAI

      58302-2PA70

    • HYUNDAI

      58302-2WA70

    • HYUNDAI / KIA

      58302-B1A05

    • HYUNDAI / KIA

      58302-B1A40

YEARS BODY FRONT ROTOR FRONT BRAKE REAR ROTOR REAR BRAKE PARKING SHOE

KIA - Borrego

02.07~09.11 HM07 US 51712-2J100 MD1202MD1384MD1385MD1917 58411-2J000 MD1284 S970

KIA - Carnival / Sedona 06

10.06~04.14 VQ MD1202MD1384MD1385MD1917 MD1284MD1439MD1816MD1916MD2021

HYUNDAI - Centennial / Equus

01.13~01.15 BHL13 51712-3N500 MD1799MD2101 58411-3N020 MD1284MD1439MD1816MD1916 S1063
09.09~05.13 BHL08 51712-3N500 MD1799MD2101MD1396 58411-3N020 MD1284MD1439MD1816MD1916 S963
02.14~09.15 BHL13 51712-3N800 MD1576 MD1284MD1439MD1816MD1916

HYUNDAI - Entourage

04.06~02.10 VQ 51712-4D500 MD1202MD1384MD1385MD1917 58411-4D500 MD1284MD1439MD1816MD1916 S918

GENESIS - G80

03.16~12.20 PB116 MD1799MD2101 MD1284MD1551MD2100 S1071S1116
03.16~12.20 PB116 MD1799MD2101 MD1284MD1551MD2100 S1071S1116

HYUNDAI - Genesis

01.08~04.14 GC41 517123M000 MD1202MD1384MD1385MD1917 58411-2M000 MD1284MD1439MD1816MD1916 S963
01.08~12.14 GC4 517123M000 MD1202MD1384MD1385MD1917 58411-2M000 MD1284 S963

HYUNDAI - Genesis Coupe

11.08~03.12 DK08 51712-3N500517122M000 MD1799MD2101MD1001MD1050MD1836MD1016(WS)MD1049MD1743 58411-3N020 MD1284 S963
03.12~12.16 DK12 US 517122M700517122M000 MD1001MD1050MD1836MD1016(WS)MD1049MD1743MD1413 58411-2M000584112M700 MD1284 S963
11.08~03.12 DK08 GNRL 517122M000517122M700 MD1413MD1001MD1050MD1836MD1016(WS)MD1049MD1743 58411-2M000584112M700 MD1284 S963
11.08~03.12 DK08 US 517122M000 MD1001MD1050MD1836MD1016(WS)MD1049MD1743MD1413 58411-2M000584112M700 MD1284 S963
03.12~08.14 DK12 517122M700517122M000 MD1413MD1001MD1050MD1836MD1016(WS)MD1049MD1743 58411-2M000584112M700 MD1284 S963

HYUNDAI - Grand Santa FE

01.13~10.18 WAGON - LONG 5DR 7P 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
10.16~10.18 WAGON - LONG 5DR 7P 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
09.12~05.16 PB813 LHD LONG 7P 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
01.13~10.18 PB813 LHD PR 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
01.13~10.16 WAGON - LONG 5DR 7P 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042

KIA - K9

09.14~03.18 DH11 MD1576 MD1284MD1439MD1816MD1916MD2021

KIA - K900

09.14~03.18 DH11 MD1576 MD1284MD1439MD1816MD1916MD2021

HYUNDAI - Maxcruz

02.13~08.15 PB813 KDOM 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
08.15~11.18 PB816 KDOM 51712-B8000 MD1202MD1384MD1385MD1917 58411-C5700 MD1284 S1042
08.15~11.18 PB816 KDOM 51712-B8000 MD1202MD1384MD1385MD1917 58411-C5700 MD1284 S1042

KIA - Mohave

01.08~10.11 WAGON - 5DR 7P 51712-2J100 MD1202MD1384MD1385MD1917 58411-2J000 MD1284MD1439MD1816MD1916MD2021 S970
10.11~03.17 PHM07 51712-2J100 MD1202MD1384MD1385MD1917 58411-2J000 MD1284MD1439MD1816MD1916MD2021 S970
01.08~03.17 HM 51712-2J100 MD1202MD1384MD1385MD1917 58411-2J000 MD1284MD1439MD1816MD1916MD2021 S970
04.17~06.19 HM16 LHD 51712-2J100 MD1202MD1384MD1385MD1917 58411-2J000 MD1284MD1439MD1816MD1916MD2021 S970
01.08~03.17 HM 51712-2J100 MD1202MD1384MD1385MD1917 58411-2J000 MD1284MD1439MD1816MD1916MD2021 S970

SSANGYONG - Musso

01.18~ PICK UP 4144136000 MD1202MD1384MD1385MD1917 48401-38000 MD1284MD1439MD1816MD1916MD2021 483KT38000
04.21~ PICK UP GRAND 4144136000 MD1202MD1384MD1385MD19174813038C00 48401-38000 MD1284MD1439MD1816MD1916MD202148413381B0 483KT38000
01.18~ QK 4144136000 MD1202MD1384MD1385MD1917 48401-38000 MD1284MD1439MD1816MD1916MD2021 483KT38000

SSANGYONG - Rexton Sports

01.18~ PICK UP 4144136000 MD1202MD1384MD1385MD1917 48401-38000 MD1284MD1439MD1816MD1916MD2021 483KT38000

HYUNDAI - Santa FE

08.15~01.19 DM15 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
08.15~01.19 DM 51712-2W000 MD1432MD1687MD1815MD2023MD2242 58411-2P000 MD1284 S1042
08.15~01.19 PDM15 RHD 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
08.15~01.19 PDM15 LHD 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
08.15~01.19 PDM15 RHD 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
07.16~02.18 DMA16 US 51712-2W000 MD1432MD1687MD1815MD2023MD2242 58411-2P000 MD1284 S1042
11.15~11.18 PB816 (USA) 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284MD1439MD1816MD1916MD2021 S1042

HYUNDAI - Santa Fe 06

12.05~07.09 CM MD1202MD1384MD1385MD1917 58411-2P000 MD1284MD1439MD1816MD1916 S981
12.05~01.13 CM MD1202MD1384MD1385MD1917 58411-2P000 MD1284MD1439MD1816MD1916 S981

HYUNDAI - Santa FE 10

08.09~08.12 SH81 LHD 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1086S981
08.09~08.12 SH81 RHD 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S981S1086
08.09~07.11 CMA10 US 51712-1U000 MD1432MD1687MD1815MD2023MD2242 58411-2P000 MD1284 S981
07.11~09.12 CMA11 US 51712-1U000 MD1432MD1687MD1815MD2023MD2242 58411-2P000 MD1284 S981
08.09~09.12 PCM10 LHD 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1086S981
08.09~09.12 SH81 SG 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S981
08.09~09.12 CMA11 US 51712-1U000 MD1432MD1687MD1815MD2023MD2242 58411-2P000 MD1284MD1439MD1816MD1916MD2021 S981
08.09~09.12 SH81 LHD 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284MD1439MD1816MD1916MD2021 S981S1086

HYUNDAI - Santa FE 12

05.12~07.15 PDM12 KDOM 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
05.12~07.15 DMA US 51712-2W000 MD1432MD1687MD1815MD2023MD2242 58411-2P000 MD1284 S1042
05.12~07.15 PDM12 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
05.12~07.15 PDM12 KDOM 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
05.12~07.15 DM LHD 51712-2W00051712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
05.12~07.15 DM RHD 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
05.12~07.15 PDM12 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042S1086
05.12~07.15 PDM12 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284MD1439MD1816MD1916MD2021 S1042

KIA - Sorento (USA)

08.14~04.18 PC615 51712-2W000 MD1432MD1687MD1815MD2023MD2242 58411-C5000 MD1284 S1042
11.14~11.20 UM 51712-2W000 MD1432MD1687MD1815MD2023MD2242 58411-C5000 MD1284 S1042
05.09~07.12 XM 51712-1U000 MD1432MD1687MD1815MD2023MD2242 58411-2P000 MD1284 S981
11.14~04.18 PC615 51712-2W000 MD1432MD1687MD1815MD2023MD2242 58411-C5000 MD1284 S1042
11.17~11.20 PC618 51712-2W000 MD1432MD1687MD1815MD2023MD2242 58411-C5000 MD1284 S1042
07.12~12.14 XM 51712-1U000 MD1432MD1687MD1815MD2023MD2242 58411-2P000 MD1284 S1042
11.14~10.20 UM 51712-2W000 MD1432MD1687MD1815MD2023MD2242 58411-C5000 MD1284 S1042
08.14~04.18 PC615 51712-2W000 MD1432MD1687MD1815MD2023MD2242 58411-C5000 MD1284 S1042
04.18~09.20 PC618 51712-2W000 MD1432MD1687MD1815MD2023MD2242 58411-C5000 MD1284 S1042
11.09~04.13 XMA09 51712-1U000 MD1432MD1687MD1815MD2023MD2242 58411-2P000 MD1284 S981

KIA - Sorento 09

05.09~07.12 KEURPXM09 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1086S981
05.09~07.12 KGENPXM09 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1086S981
05.09~07.12 XM09 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S981
05.09~07.12 XM09 GL 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S981
05.09~07.12 XM09 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1086

KIA - Sorento 12

07.12~08.14 XM12 KDOM 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
07.12~ XM12 CKD VTN 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
07.12~08.14 XM12 LHD 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
07.12~08.14 XM12 RHD 51712-2B70051712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
07.12~08.14 XM12 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
07.12~08.14 XM 51712-2B700 MD1202MD1384MD1385MD1917 58411-2P000 MD1284 S1042
07.12~08.14 XM12 51712-2W000 MD1202MD1384MD1385MD1917 58411-2P000 MD1284MD1439MD1816MD1916MD2021 S1042
